SKU : LSBE025-P250
หมวดหมู่ : LED Full Color Display Billboard Advertising ,  Indoor ,
แบรนด์ : LG
Share
Physical Parameters
Pixel Configuration : Single SMD
Pixel Pitch(mm) : 2.50
Module Resolution (WxH) : 120x135
Module Dimensions(WxH,mm) : 300x337.5x13
Weight per Module (kg) : 0.95
No. of Modules per Cabinet (WxH) : 2x1
Cabinet Resolution (WxH) : 240x135
Cabinet Dimensions (W x H x D, mm) : 600x337.5x72
Cabinet Surface Area (㎡) : 0.203
Weight per Cabinet (kg/unit) : 6.5
Weight per Square Meter (kg/m²) : 32.0
Physical Pixel Density (pixels/m²) : 160,000
Flatness of Cabinet (mm) : ±0.3
Cabinet Material : Die-casting Aluminum
Service Access : Front
OPTICAL SPECIFICATIONS
Max Brightness (After Calibration, nit) : 600
Color Temperature (K) : 3,200~9,300
Visual Viewing Angle (Horizontal) : 160
Visual Viewing Angle (Vertical) : 150
Brightness Uniformity : 97%
Color Uniformity : ±0.003Cx,Cy
Contrast Ratio : 5,000:1
Processing Depth (bit) : 14
ELECTRICAL SPECIFICATIONS
Power Consumption (W/Cabinet, Max.) : 93
Power Consumption (W/Cabinet, Avg.) : 36
Power Consumption (W/m², Max.) : 460
Heat Dissipation (BTU/h/Cabinet, Max.) : 317
Heat Dissipation (BTU/h/Cabinet, Avg.) : 122
Heat Dissipation (BTU/h/m², Max.) : 1,570
Power Supply (V) : 100 to 240
Frame Rate (Hz) : 50 / 60
Refresh Rate (Hz) : 3,840
OPERATION SPECIFICATIONS
LED Lifetime (Half brightness) : 100,000
Operating Temperature() : -20 to +40
Operating Humidity : 10~80%RH
IP Rating Front : IP50
IP Rating Rear : IP50
Standard
Certification : CE, FCC, cTUVus, CB, KC, CCC
Environment
Environment : RoHS, REACH
Controller
Controller : CVBA
90 Degree Corner Cut
90 Degree Corner Cut : Yes
Series
Series : LSBE
